CTP-S Double Coating
The cost-effective of CTP Thermal Plate enables users to enjoy high- performance printing at a low cost from the world first-class plate manufacturers . It is an ideal choice of typographers with high requirements of printing precision.
EMAIL：136230233@qq.com
Classification:
Products
CTP Edition
- Product Description
- Product Parameters
-
Hengju CTP Thermal Plate is a special one for the medium- and high-grade thermal CTP plate-making.
The cost-effective of CTP Thermal Plate enables users to enjoy high- performance printing at a low cost from the world first-class plate manufacturers . It is an ideal choice of typographers with high requirements of printing precision.
Hengjiu CTP Thermal Plate adopts an infrared laser with the wave of 830nm in exposure. The plate can reach 50,000 impressions without baking through the developing process, andit can
realize over long printing after baking. it is not only suitable for UV ink printing,but also suitable for ordinary ink printing.
Stable property
The technology of Thermal Plate has excellent comments in the industry possess with the following performances, such as stabilities, reliabilities and exactness. Hengjiu CTP Thermal Plate
adhering to these advantages, let users at ease use.
Hengjiu CTP Thermal Plate can provide a consistent and foreseeable result with a rapid reproduction and excellent water-ink balance. It can meet a high. precision requirement.Good compatibility
Hengju Thermal CTP Plate is easily operated with wide latitude of plate-making and developing.It is compatible with various models of popular thermal plate-setters in the market.Specifications complete
Hengjlu CTP Thermal Plate provides various sizes of plates and packages. It can meet the requirements of different specifications.
Powerful services
Hennan Hengjiu has a powerful technical team with highly skilled and first- class services. Let users at ease use.
-
Test items CTP- S、CTP- 1 Plate Positive working and no preheating with excellent dot reproduction.
The size, thickness and package are strictly stipulated.Substrate High-quality grained and anodized aluminum substrate. Laser energy 110- 120 mi/cm2 (In order to achieve the highest print quality, the laser energy can make adjustments according to the type of imaging devices, developing conditions and resolutions). Application Ordinary qualities in the general applications for short or long printing in the sheet-fed commercial market. Thickness of substrate 0.15mm/0.20mm/0.25mm/0.27mm/0.40mm Maximum width 1640mm Spectral sensitivity 800- 850nm Plate-setter compatibility All the main thermal CTP plate-setters in the market. Output resolution 1-99% @ 200lpi Safelight Within 2 hours in daylight Run length Unbaked: 50,000- 80,000 impressions with ordinary printing ink Baked: 100,000- 150,000 impressions with ordinary printing ink Unbaked: 50,000- 80,000 impressions with UV/EB ink.
(Dependent upon the conditions including imaging resolutions, presses, chemicals, ink and paper.)Shelf life 12months, under recommended storage conditions Transport and storage Recommended conditions: temperature 17- 25C& RH between 25 -60% in package.
Transported in terms of refrigerators.
