The Product Instruction of Hengjiu (CTCP plate)
CTCP positive (UV-CTP plate)
Hengjiu CTCP positive UV-CTP plate is a kind of high quality UV-CTP plate developed by our research department , which make the printing enterprise in the production of both economic efficiency at the same time. It is widely used in sheet-fed and web commercial press.
Specially designed for UV Technology
Hengjiu CTCP positive UV-CTP plate is a UVCTP plate developed to meet the market requirements for plate-making speed and eficiency.The plate which is specifically designed for the CTCP technology, the features of CTCP is that a new UV photosensitive layer formula and high quality electrolytic oxidation of the aluminum base,It could meet the various demands in the printing business.
Excellent printing performance
The new photosensitive layer formula and high quality substrate treatment technology make the plate has a precisely dot reduction, excellent ink balance performance and superior wear resistance. The run length is up to 50,000-80, 000 sheets under the UV ink printing.under the ordinary ink,run length can be up to more than100,000- 150, 000 sheets.(Dependent upon the conditions including imaging resolutions, presses, chemicals, ink and paper,)
Low effect of environment
Hengjiu CTCP positive UV-CTP plate can be used directly to Environmental friendly UV ink,reducing volatile organic solvents(VOC) emissions in the printing process.The high run length reduces the amount of media used in the process, saving costs and time.High run length, reduce the usage of plate in long printing and save cost and time in production.
Hengjiu CTCP positive UV-CTP plate can improve the prepress preparation efficiency, while maintaining high print volume, greatly reducing the waste of paper and ink.
Hengjiu CTCP positive plate needs baked only in extreme conditions,such as rough paper, corrosive chemicals, long length impressions.
-
Plate type CTCP-1, CTCP-S positive plate Gauges 0.15mm/0.20mm/0.25mm/0.27mm/O.40mm Substrate Electrochemically grained and anodized aluminum substrate. Application Commercial Sheet fed and rotary press printing. Spectral sensitivity 350- 420nm UV, especially 400-4 10nm UV laser. Plate setter Compatible with mainstream CTcP-1 plate setter in the market. Exposure energy 30- 35mW(Corey UV- 4632CI plate setter, parameters 1000 rpm) Resolution 2 to98% @ 2501pi(Platesetters in different resolution will have difference). Processor Compatible with mainstream processor in the market Developer The ratio of
developer (PD: water)PD positive PS plate developer are recommended1:3- 1:4 Developer temperature
Developing time
Replenishing Rate24士1°C
20-30 seconds
100-150ml/mSafe light yellw light Working conditions Operating temperature21-25℃
(room temperature), relative humidity 40-60%Storage condition Storage temperature 15-27C.relative humidity 25- 60%.
18 months. in the recommended storage conditions.
